C2SR, Rfid/Mifare, IP65

Anviz C2SR Access Control: Rfid/Mifare Reader, for outdoor IP65, 32 Bit high speed CPU, Wiegand 26/34.

Anviz C2SR is a compact access control reader designed to adapt to any type of gate. C2SR has a refined design and is waterproof with IP65 protection rating, ideal for outdoor installations. 32 bit high speed CPU. C2SR is equipped with a double reader for RFID 125kHz and Mifare 13.56 Mhz cards. C2SR has interfaces with Wiegand 26/34 protocol and can be interfaced to any access control terminal equipped with Wiegand In.





It is an ANVIZ product, distributed exclusively by Osti Sistemi.




Functions and equipment

RFID card reader
Mifare Card Reader
Degree of protection IP65

Features

  • 32 Bit High Speed CPU.
  • Slim and elegant design.
  • For outdoors with IP65 protection rating.
  • Double readers: RFID 125 Khz and Mifare 13.56 MHz.
  • Card reading range up to 50 mm.
  • LED indicators and buzzer for visual and audio feedback
  • Wiegand communication interface: interfaceable with all Wigand In terminals.

Tecnology

  • IP65 protection rating.
  • High speed 32 Bit CPU.
  • Double reader: RFID EM 125KHz and Mifare 13.56 Mhz cards.
  • Card reading range up to 50 mm.
  • Interfaces: Wiegand 26/34.
  • Support Wiegand In protocol.
  • Multicolor LED interface and voice buzzers.
  • Operating voltage 12V DC.
  • Operating temperature -10°C to 65°C
  • Dimensions: (WxHxD) 50 x 159 x 25 millimetres.
  • DC 12V power supply not included.
  • Certificates: CE, RoHS.

Functions and equipment

RFID card reader
Mifare Card Reader
Degree of protection IP65
