C2CPro Rfid Wi-fi PoE Linux

Time attendance and access control Anviz C2C Pro: Rfid attendance terminal, high performance Linux operating system with tcp / ip PoE and Wi-fi.

Anviz C2C Pro is a high performance time and attendance terminal aimed to the middle and high-end market. Equipped with highly efficient Dual-Core 1GHz processor. Friendly GUI and 3.5 inches TFT LCD make C2 Pro is easy to use. It support several RFID reader module (HID, ALLEGION or ANVIZ) and RS485, PoE-TCP/IP or WiFi communication for different requirements. Based on Linux operation system, C2 Pro offers SDK and EDK for further customization of the system. It also provides 1 relay for the ringbell and a connecting to the Access Control system. All the above to meet your requirements.





Functions and equipment

RFID card reader
PIN code
Web server
LAN network card
PoE (power over ethernet)
Wi-fi
USB pen drive
Ringtones
Management software

Features

  1. Linux platform to provide a safe and stable performance
  2. PoE-TCP/IP or WiFi communication for different requirements
  3. Provide 1 relay for belling and connecting to Access Control system
  4. RS232 interface can be connected to a Time & Attendance printer
  5. Using new material as cover make it more attractive and durable
  6. With humanized design, the entirely new rubber keypad brings better user experience
  7. Bigger and brighter 3.5 inch color display
  8. Installation became fast & easy through optimal design of wall-mounted board >
  9. Ease the experience of user by brand new UI design

Tecnology

  • Platform                       Linux
  • CPU                             Dual-Core 1GHz Processor
  • Memory                       512M DDR3+2GB Flash
  • LCD                             3.5” TFT
  • LED                             Three-color indicator light
  • Operating Temperature   -20°C to 50°C
  • Humidity                      0% to 90%
  • Verification Mode          Password,Card
  • Logs                            100,000
  • Card                            125Khz EM, optional 13.56MHz Mifare
  • WiFi                             Yes
  • TCP/IP                         Yes
  • RS-232                         Yes
  • Relay                           1 Relay
  • USB                             1 Host
  • Web Server Yes
  • Power DC 5-12V 1A
  • Dimensions 140(W) x 190(H) x 32(D) mm

Functions and equipment

RFID card reader
PIN code
Web server
LAN network card
PoE (power over ethernet)
Wi-fi
USB pen drive
Ringtones
Management software
